New Products

Integrated Air Bearings Heat Pipes
In today’s manufacturing environ- Advanced Thermal Solutions, Inc.
ment, moving machinery to optimize (ATS) (Norwood, MA) has expanded its
floor space, flex for lean manufacturing, line of flat and round copper heat pipes
or position for optimum productivity is for electronics thermal management.
imperative. Embedding air bearings on ATS heat pipes transfer component
OEM machinery provides manufacturers heat with minimal temperature differ-
with the ultimate capability to adapt and flex to ever-chang- ence to dispense heat efficiently across heat spreaders. Liquid in
ing manufacturing configurations. Embedded air bearings can the heat pipe turns to vapor by absorbing heat and removing
now be designed into the OEM equipment via an online thermal energy from hot component surfaces. The vapor travels
toolkit available from AeroGo (Seattle, WA). to the cold end of the pipe, releases latent heat and condenses
Air bearing systems utilize compressed air to lift and float back to liquid. The liquid returns to the hot interface along an in-
heavy machines, structures and tooling within their own foot- ternal copper wick to provide continuous thermal management.
print. Air bearing technology works similar to a puck on an air Every ATS heat pipe consists of a sealed copper tube, inter-
hockey table, in that it eliminates friction – making heavy nal copper wick structure, and distilled water as its working
loads easy to move – and it floats on the surface without dam- fluid. Round profile heat pipes come in lengths from 200-300
aging the floor. This material handling method is inherently mm and diameters from 4.0-8.0 mm. Flat profile heat pipes
safe to operators due to very low lift height and reduced fric- range in length from 100-250 mm, widths from 8.2-10.5 mm,
tion/low chance of strain. The embedded air bearing system is and heights from 2.5-4.5 mm. Weights range from 8-33
permanently integrated into the tool, machine, or structure. grams. They are effective in temperatures ranging from 30-
Wheeled casters, footers or bases are fitted with air bearing 120°C. Other fluids and sizes can be accommodated with cus-
modules and a control console for adjustable air control. tom heat pipe designs by ATS.
For Free Info Visit http://info.hotims.com/76503-488 For Free Info Visit http://info.hotims.com/76503-491
Graphics XMC
Abaco Systems (Huntsville, AL) recently expanded its grow-
ing range of video/graphics solutions with the launch of the
rugged, high bandwidth NVP2102A XMC Graphics and GPGPU
Card. Designed to complement the recently-announced NVP2102, the
NVP2102A offers additional support for legacy interfaces and peripherals.
®
®
Based on the NVIDIA Quadro Pascal™ (GP107) P2000 GPU architecture and provid-
ing up to 2.3 TeraFLOPS of peak performance, target applications for the new board in-
®
clude those that require very high-end graphics capabilities or CUDA support when
performing general purpose processing, and that require raw video capture and display.
The NVP2102A is competitively advantaged by its provision of four 3G-SDI inputs –
twice the number typically found. It also provides two NTSC/PAL video inputs as well
as supporting two audio inputs. Video output is via two 3G-SDI and two DVI or Display-
™
Port interfaces.
For Free Info Visit http://info.hotims.com/76503-490

Compact, Directional Coupler
KRYTAR, Inc. (Sunnyvale, CA) has announced a new direc-
tional coupler operating in the frequency range of 6.0 to
40.0 GHz offering nominal coupling of 20 dB in a compact
package. Directional coupler, Model 106040020, provides so-
lutions for many applications covering microwave fre-
quency bands from L through K-Band including electronic
warfare (EW), commercial wireless, SATCOM, radar, signal monitoring and measure-
ment, antenna beam forming, and EMC testing environments.
The new directional coupler delivers nominal coupling (with respect to output) of
20 dB, ±1.0 dB, and frequency sensitivity of ±0.50 dB. The directional coupler exhibits
Insertion Loss (including coupled power) of less than 1.2 dB, directivity of greater than
12 dB, maximum VSWR (any port) is 1.6. Input power rating is 20W average and 3 kW
peak. Operating temperature is -54°C to +85°C. The unit comes in a compact package
measuring just 1.40 inches (L) ¥ 0.45 inches (W) ¥ 0.69 inches (H), it weighs only 1.2
ounces, and includes 2.4 mm female connectors.
For Free Info Visit http://info.hotims.com/76503-474
